According to the EN ISO 544 standards, the maximum diameter tolerance of the wire for metal shielding gas welding is set at +0.01/-0.04 mm. These limits being fully used would lead to an alteration of more than 8 % of the cross section of the wire. In the welding process this means the speed of the wire feeder has to be corrected with up to 8 % to keep the same processing properties.
Mig Weld keeps tolerances steadily around +0.0/-0.02 mm thus limiting the highest wire feed speed deviation to 3.31 %.
Paragraphes
Colonne 1
| Diamètre | |
|---|---|
| [mm] | Deviation |
| 1,21 | +0,83% |
| 1,20 | 0,00% |
| 1,18 | -1,67% |
| 1,16 | -3,33% |
| Section | |
|---|---|
| [mm2] | Deviation |
| 1,15 | +1,65% |
| 1,13 | 0,00% |
| 1,09 | -3,31% |
| 1,16 | -6,56% |
Colonne 2
Approvals
Our welding wires have many approvals.
